China 37.5kva 30kw silent canopy diesel light generator by Weichai

FOB Reference Price:Get Latest Price
US $2,500-3,000 / Set
Supply Ability:
1000 Piece/Pieces per Month
Port:
Huangpu port Guangzhou
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
VLAIS
Model Number:
KDE-40T
Output Type:
AC Three Phase
Speed:
1500/1800rpm
Frequency:
50/60HZ
Rated Power:
30kw
Rated Voltage:
110V/230V/400V
Rated Current:
72.2A
Engine Model:
4100ZD
Cylinder number:
4
Rated Rotation Speed:
1500rpm
Starting system:
Electric strater
Exicitation mode:
Self-excitation and cinstant voltage
Bore*Stroke:
100*115mm
Fuel consumption at full load:
221(g/kw.h)
Certificate:
CE
Dimension(L*W*H):
2200*1000*1400mm
Net Weight(KG):
1290
Packaging & Delivery
Packaging Details
wooden package
Delivery Time
Shipped in 12 days after payment
Product Description

Product Application

VLAIS CE Approved generator features with high-quality engine core, strong and stable output performance, lower fuel comsumption, silently working condition, Smart and automatic controller as operating protection. It is applied to all industrial and life such as hospital, school,hotel and production plant. necessary and fond. Have vlais have future.

SPECIFICATIONS FOR 30 KW DIESEL GENERATOR

Engine
Engine model
Kw/rpm
30/1500
No. of cylinders
Number
4
Rated Power
kw
30

Main performance parameters
Max.Output
kva
37.5
Rated Voltage/Frequency
v/hz
230/400V/50HZ
Bore*Stroke
mm
100*115

Hydraulic system
Fuel consumption at full load
g/kw.h
221
Dimension(L*W*H)
mm
2000*900*1400
Net Weight
Kg
1100

Main Features

1) Stable and stronge power outlet-AVR and Original weifang engine
2) Lower fuel consumption-230g/kw.h Fuel consumption(g/kw.h) at full load
3) Silently working condition-100-105 DB at 7m
4) Professional operating manual and maintainance direction.
5) The quality have completely assurance-CE certificate

Certifications
Detailed Images

Smart Controller

Name: Smartgen

Brand:

Original: China

In VLAIS Power, we are using generator controllers Integrating digital, Intelligent and network techniques are used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.

All copper coil

Name: All copper coil

Original:China
All copper coil allow generator have higher-effective power output, Longer lifespan, Lower working noise level and Cheaper maintaining cost.

Brushless alternator

Name:ST Alternator
Original: China
Brushless alternator allow our generators to have more effective output, Lower noise, longer lifespan and cheaper maintaining cost.

Main Features

Name: Bliwing Cylinder
Brand: FESTO
Original: Germany
The set is designed for easy and convenient transportation and move.Round pulley is made by Z-iron differing from other pulley.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.


Inspect generator and data analysis.
Inspect and data analysis 10 pieces of 25kva silent diesel generator for Clients from Turks and Caicos Islands.

Packing & Delivery
Packaging and Sea delivery
Size
2000 (L) * 900 (W) * 1400 (D)
Weight
1.1T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
